CONSTRUCTION & SPECIFICATION: –
 Outer chamber is made of high-grade powder coated mild steel.
 Inner chamber made of stainless steel 304 grade rust and dust proof.
 Motorized Air Circulating Blower, strong dispersion and maintains higher temperature uniformity inside the chamber.
 Door has viewing window to observe the sample placed inside the chamber without disturbing the thermal condition.
 Thermal loss is prevented by filling 75mm by glass wool in space between the outer body & Inner chamber.
 Door Gasket fixed on the double walled door for proper sealing.
 Fitted with heavy hinges with a ball catcher, spring loaded door closing device. Door is duly insulated.
 Adjustable two ventilation slides control inner air / vapour circulation.
 Beaded heating elements made of high quality Nichrome / Kanthal wire are placed in ribs, at bottom and sides i.e. on three sides of
the cabinet for uniform heat distribution.
 Inner chamber has ribs for placing the shelves at convenient levels. Supplied with 2 removable type shelves.
 Temperature is controlled by electronic digital temperature indicator cum controller.
 Different programmed functions can be designed for a wide variety of applications, and even when used (Optional)
 Temperature is displayed by Digital LED with SV and PV display at front of the oven.
 Front Panel is provided with ON/OFF switch, temperature controller and indicators
 Operating Voltage: 220 Volts AC (50 Hz).
 Inbuilt Over temperature protection, Auto power break off & Safety alarm system.
