Technical Features

Product Overview/Applications

• The Ocean Life Science Corporation Plant Growth Chamber is a state-of-the-art environmental simulation chamber specifically engineered
  for advanced plant research, seed germination, tissue culture, insect studies, and controlled-environment experiments. The chamber offers
  precise control of temperature, humidity, lighting, and optional CO₂ enrichment to ensure highly reproducible and reliable research
  conditions.
•  The chamber is designed with flexible two-tier and three-tier growth configurations, enabling researchers to maximize usable growth area
  according to their experimental requirements.

Lighting System

• Exterior body constructed from wet-painted galvanized steel for superior corrosion resistance and long service life.
• Interior fabricated from reflective white, wet-painted galvannealed steel.
• This facilitates precise light intensity levels to be maintained throughout the life of experiment.
• Standard color choices include cool white, full-spectrum LEDs.
• Non-standard color choices include blue, red, far red, red-blue-far red combination, red-green-blue combination, red-blue-far red-white combination LEDs.
• 1,100 μmol m⁻² s⁻¹ at 15–20 cm from light source (Two-Tier), 775 μmol m⁻² s⁻¹ per tier at 15–20 cm from light source (Three-Tier ).
• IP-rated LED fixtures and drivers, Open-loop programmable dimming, Balanced broad-spectrum LEDs, Supplemental far-red fixtures, Additional 10% far-red output when enabled, Uniform light distribution throughout the chamber.
• Each color of the lights is independently regulated and dimmable from 0% to 100%.
• Programming and control of the lighting is done via HMI touch screen real time controller.

Safety Limit Controls

• Adjustable high and low temperature/humidity/pressure controls, audible alarms, and visual indicators display on the screen.
• Controls shut down all power to the chamber, activating alarms (when the temperature/humidity /pressure returns to the normal range, the system will automatically reset).
• Backup “high/low” alarms provide a further level of protection while visual and audible notification is provided when any alarm be activated. Contacts for connection to a remote management system are also included.
• One access port of approximately 50 mm diameter with light-tight cap
