Technical Features

❖ Suitable for Hazardous Biological Applications.
❖ Confirms the Air cleanliness standard ISO 14644-5 (Class 100)
❖ Free Blower ensures noiseless operation.
❖ Designed for handling hazardous biological materials and chemical vapors.
❖ Sound level no more than 60 decibel ± 5%.
❖ Microprocessor controlled, Class II Bio Safety Cabinet (Type B2)
❖ All contaminated air paths remains in negative pressure.
❖ The exhaust plenum remains under negative pressure & hard ducted to the outside environment.
❖ Ergonomically angled supply filter to match cabinet profile for down flow uniformity.
❖ Smooth rounded corners for easy cleaning.
❖ Main Supply & Exhaust filter – Mini pleat HEPA filter with particle retention 99.99% for 0.3 micron particles.
❖ Workstation outer body made of Electro galvanized steel duly powder coated.
❖ Working chamber is made of stainless steel 304.
❖ Single removable stainless steel 304 perforated working surface with spill-retaining design.
❖ Smooth finish interior and exterior ensures no risk of cuts to the user or maintenance personnel.
❖ The front vertical sliding sash made of transparent toughened glass (5-mm thickness) with smooth counter balanced drive.
❖ Interlocking Microprocessor PID Control with Digital PV & SV Display, Blower & UV Control, LED Light Control, Alarm Monitoring, UV Timer, Filter Status Monitoring, Alarm Functions, and Optional Password Protection.
❖ Built-in “PHILIPS” UV, Germicidal light helps in killing bacteria and other microorganism.
❖ Working area is illuminated by bright uniform shadow-free illumination Fluorescent LED light (1x40W).
❖ Duly dynamically balanced highly efficient centrifugal blower with 0.25 HP Motor Mounted on anti vibration pad.
❖ 1440rpm motor unit sized to generate adequate air flow volume over the Filter.
❖ Height of the working table provides comfortable “SIT DOWN” working position for the operator.
❖ Gas tap-one towards the back of the cabinet, Fumigation Port (Optional).
❖ Magnehelic gauge for pressure monitoring.
❖ 2 Nos-15/5A electrical outlets inside the work space.
❖ Supplied complete with cord & plug to work on 220-240VAC, 50Hz supply.
